Construction:
- Tube: PA (polyamide).
- Reinforcement: One layer of textile braid.
- Cover: PU (polyurethane), Orange non-conductive
Temperature:
-40°C to +100°C (intermittent 110°C)
Specifications
| Size | Inside Diameter | Outside Diameter | Working Pressure | Bursting Pressure | Bend Radius | Weight | Length | ||||
| Dash | mm | Inch | mm | mm | bar | psi | bar | psi | mm | kgs/m | m |
| R7N-02 | 3.2 | 1/8" | 3.4-3.6 | 8.5 | 224 | 3248 | 896 | 12992 | 19 | 0.038 | 90-110 |
| R7N-03 | 4.8 | 3/16" | 4.6-5.4 | 10.8 | 224 | 3248 | 896 | 12992 | 19 | 0.080 | 90-110 |
| R7N-04 | 6.4 | 1/4" | 6.2-7.0 | 13 | 210 | 3045 | 840 | 12180 | 38 | 0.120 | 90-110 |
| R7N-05 | 7.9 | 5/16" | 7.7-8.5 | 15.1 | 175 | 2538 | 700 | 10150 | 44 | 0.145 | 90-110 |
| R7N-06 | 9.5 | 3/8" | 9.3-10.1 | 17.0 | 158 | 2291 | 632 | 9164 | 51 | 0.170 | 90-110 |
| R7N-08 | 12.7 | 1/2" | 12.3-13.5 | 20.7 | 158 | 2291 | 632 | 9164 | 76 | 0.250 | 90-110 |
| R7N-10 | 15.9 | 5/8" | 15.5-16.7 | 25.0 | 192 | 2784 | 768 | 11136 | 152 | 0.300 | 45-55 |
| R7N-12 | 19.1 | 3/4" | 18.6-19.8 | 26.0 | 88 | 1276 | 352 | 5104 | 127 | 0.346 | 45-55 |
| R7N-16 | 25.4 | 1" | 25.0-26.4 | 32.0 | 70 | 1015 | 280 | 4060 | 203 | 0.422 | 45-55 |
