Caratteristiche principali:
Pressione di esercizio nominale EN/DIN e nuova SAE
Proprietà ignifuga della copertura
Approvato da MSHA hydraulic hose R3
Copertura liscia approvata FRAS
Brand hose layline OEM
|
Numero parte |
ID |
OD |
Parola chiave |
BP |
Brasile |
Peso |
|||
|
Trattino |
Pollice |
mm |
mm |
MPa |
PSI |
MPa |
PSI |
mm |
kg/m |
|
R3-04 |
1/4 |
6.3 |
12.6 |
10.5 |
1523 |
42 |
6090 |
75 |
0.145 |
|
R3-05 |
5/16 |
7.9 |
14.1 |
8.7 |
1262 |
35 |
5075 |
75 |
0.182 |
|
R3-06 |
3/8 |
9.7 |
16.8 |
8.4 |
1218 |
34 |
4930 |
100 |
0.253 |
|
R3-08 |
1/2 |
12.7 |
18.4 |
7.8 |
1131 |
31 |
4495 |
100 |
0.282 |
|
R3-10 |
5/8 |
15.8 |
23.0 |
7.0 |
1015 |
28 |
4060 |
125 |
0.416 |
|
R3-12 |
3/4 |
19.0 |
26.7 |
6.1 |
885 |
24 |
3480 |
140 |
0.499 |
|
R3-14 |
7/8 |
22.3 |
31.0 |
5.2 |
754 |
21 |
3045 |
150 |
0.697 |
|
R3-16 |
1 |
25.4 |
37.5 |
3.9 |
566 |
16 |
2320 |
205 |
0.844 |
|
R3-20 |
1.1/4″ |
31.8 |
45.0 |
2.6 |
377 |
10 |
1450 |
250 |
1.004 |
Applicazione:
Low medium pressure line, return lines.
It is suitable for delivering petroleum or water-based hydraulic fluids. It is mainly used in low pressure conditions and it is also used in pneumatic applications.
La nostra azienda:
We are glad to introduce our company SINOPULSE HOSE FACTORY CO.,LTD. 18 years experience.
As profesional manufacturer of hydraulic hoses, we mainly produce
Hydraulic hose R1AT, R2AT, 1SN, 2SN,4SP, 4SH, R12, R13, R15, R6, R7, R8.
Low pressure Air/water/oil rubber hose /Suction hoses,
Hydraulic Fitting Metric, JIC, BSP, ORFS
Our factory is certified by ISO2008:9001 and MSHA USA IC-341/01.
We exported to 60 countries in Europe,South America, Middle East and Asia etc.
We mainly produce for reliable customers in Europe and America countries and have good prestige, since our consecutive quality, strict testing, reasonable low prices, quality warranty, and 100% responsibility.
For more further informations, you can contact us without any hesitation.
Hope sincerely we can biuld up long time mutual cooperation.
Disponiamo di un'ampia gamma di tubi idraulici, in grado di soddisfare le vostre diverse applicazioni.
SAE100 R1AT/EN 853 1SN (ONE STEEL WIRE BRAIDED HYDRAULIC HOSE)
SAE100 R2AT/EN853 2SN (TWO STEEL WIRE BRAIDED HYDRAULIC HOSE)
DIN 20023/EN 856 4SP (FOUR STEEL WIRE SPIRAL HYDRAULIC HOSE)
DIN 20023/EN 856 4SH (FOUR STEEL WIRE SPIRAL HYDRAULIC HOSE)
SAE100 R12 (FOUR STEEL WIRE SPIRAL HYDRAULIC HOSE)
SAE100 R13 (FOUR OR SIX STEEL WIRE SPIRAL HYDRAULIC HOSE)
SAE100 R15 (SIX STEEL WIRE SPIRAL HYDRAULIC HOSE)
EN 857 1SC (ONE STEEL WIRE BRAIDED HYDRAULIC HOSE)
EN857 2SC (TWO STEEL WIRE BRAIDED HYDRAULIC HOSE)
SAE100 R16 (ONE OR TWO STEEL WIRE BRAIDED HYDRAULIC HOSE)
SAE100 R17 (ONE OR TWO STEEL WIRE BRAIDED HYDRAULIC HOSE)
SAE100 R3 / EN 854 2TE (TWO FIBRE BRAIDED HYDRAULIC HOSE)
SAE100 R6 / EN 854 1TE (ONE FIBRE BRAIDED HYDRAULIC HOSE)
SAE100 R5 (FIBER BRAIDED COVER HYDRAULIC HOSE)
SAE100 R4 (HYDRAULIC OIL SUCTION HOSE)
SAE100 R14 (PTFE SS304 BRAIDED)
SAE100 R7 (ONE WIRE OR FIBRE BRAIDED THERMOPLASTIC HOSE)
SAE100 R8 (TWO WIRE OR FIBRE BRAIDED THERMOPLASTIC HOSE)
